| Quantity: | |
|---|---|
Model | 1250mm Double-layer | 1250mm Single-layer |
| Screw Diameter (mm) | 65 | 75 |
| Ratio of Screw (L/D) | 30:1 | 30:1 |
| Width of Die Head (mm) | 1250 | 1250 |
| Width of Finished Products (mm) | 1000(500x2roll) | 1000(500x2roll) |
| Thickness of Finished Products (mm) | 0.017-0.05 | 0.017-0.05 |
| Structure of Film layers | A/B | -- |
| Max Output (kg/h) | 100 | 100 |
| Linear Speed of Machinery (m/min) | 50-100 | 50-100 |
| Total Power (kw) | 140 | 120 |
| Overall Dimension (LxWxH)m | 10x4x3 | 11x4.5x3 |
| Weight (T)(About) | 8 | 8 |
Model | 1250mm Double-layer | 1250mm Single-layer |
| Screw Diameter (mm) | 65 | 75 |
| Ratio of Screw (L/D) | 30:1 | 30:1 |
| Width of Die Head (mm) | 1250 | 1250 |
| Width of Finished Products (mm) | 1000(500x2roll) | 1000(500x2roll) |
| Thickness of Finished Products (mm) | 0.017-0.05 | 0.017-0.05 |
| Structure of Film layers | A/B | -- |
| Max Output (kg/h) | 100 | 100 |
| Linear Speed of Machinery (m/min) | 50-100 | 50-100 |
| Total Power (kw) | 140 | 120 |
| Overall Dimension (LxWxH)m | 10x4x3 | 11x4.5x3 |
| Weight (T)(About) | 8 | 8 |
